Application of J1939 Splitter Y Cable With Right Angle Connectors
The " J1939 Splitter Y Cable With Right Angle Connectors" refers to the J1939 right angle splitter Y cable. The following is an introduction to it:
purpose
Vehicle diagnosis and monitoring: commonly used in electronic systems of commercial vehicles, heavy trucks, and other vehicles to facilitate the connection of multiple diagnostic devices or sensors, enabling real-time monitoring and fault diagnosis of key components such as vehicle engines, transmissions, and braking systems.
Data transmission extension: It can distribute data signals on the J1939 bus to multiple devices, such as electronic control units (ECUs), display screens, recorders, etc., to ensure stable data transmission between devices and achieve collaborative work of various vehicle functions.
Structure Design
Right angle connector: adopting a right angle design, it can flexibly route cables in limited space, avoiding excessive bending of cables or occupying too much space, improving installation convenience and flexibility, and reducing the occupation of internal space of the vehicle.
Y-shaped splitter: It has one input port and two output ports, which can split one J1939 signal into two paths, allowing one J1939 interface to connect two different devices simultaneously, achieving signal distribution and sharing.
9-pin connector: Typically equipped with a 9-pin connector that complies with the J1939 standard, it can perfectly match the J1939 interface on the vehicle, ensuring the stability and reliability of signal transmission.
