How to determine whether J1939 cable needs maintenance in car repair?
In car maintenance, the need for maintenance of J1939 cables can be determined from the following aspects:
View appearance
Check the cable sheath: Observe whether the cable sheath is damaged, cracked, deformed, or discolored. If the outer skin is damaged, it may expose the internal wires and shielding layer, making them vulnerable to external environmental influences and requiring timely maintenance or repair.
Check the shielding layer: Check whether the shielding layer of the cable is damaged, such as whether the woven mesh is loose or broken, and whether the aluminum foil is damaged or wrinkled. The damage of the shielding layer will affect the anti-interference ability of the cable, causing problems in signal transmission. In this case, it is necessary to maintain the cable, repair or replace the shielding layer.
Check the connection parts: Check whether the joints at both ends of the cable are loose, oxidized, corroded, etc. Loose joints can increase contact resistance and affect signal transmission; Oxidation and corrosion may damage the conductivity of the joint and cause communication failures. If these problems are found, it indicates that the connection parts of the cable need maintenance, such as cleaning, fastening joints, etc.
Testing electrical performance
Measure resistance: Use a multimeter to measure the resistance value of the cable, including wire resistance and shielding layer resistance. If the resistance value exceeds the normal range, it may be due to open or short circuits in the internal wires of the cable, or problems with the shielding layer, which requires further inspection and maintenance.
Check insulation performance: Use an insulation resistance tester to measure the insulation resistance of the cable to determine if the insulation layer is in good condition. If the insulation resistance value is too low, it indicates that the insulation layer may be damaged or damp, which will affect the performance and safety of the cable, and requires drying treatment or repair of the insulation layer.
Evaluate signal transmission quality: With the help of professional diagnostic equipment, such as automotive fault diagnosis devices, detect the J1939 communication network of the vehicle. Check for signal loss, increased bit error rate, communication delay, and other issues. If these situations exist and the possibility of other equipment failures is ruled out, it indicates that J1939 cables may need maintenance to improve signal transmission quality.
